Uniross ML2020 lithium-aluminium rechargeable coin cells deliver 40 mAh at 3V in a 20.0mm diameter, 2.0mm profile — 33% more capacity than the ML2016 in the same footprint with a 0.4mm height increase. Where the mechanical design permits the 2.0mm height, the ML2020 is the preferred specification for rechargeable 20mm coin cell applications: it delivers the maximum energy available in the 1.6–2.0mm height range while maintaining 400 cycle capability at 10% DOD. Suitable for CMOS/RTC backup, ESL, and embedded sensor applications requiring a rechargeable 20mm coin cell. Available in bulk from European stock.
| battery-type | ML2020 |
|---|---|
| chemistry | Lithium Aluminium (Li-Al) |
| nominal-voltage-v | 3V |
| nominal-capacity-mah | 40 mAh |
| standard-current-ma | 0.2 mA |
| charge-discharge-cycle | 400 (10%DOD) / 180 (20%DOD) |
| max-dimensions-mm | ø20.0 x 2.0 mm |
| weight-approx-g | 2.2 g |
| shelf-life | 5 Years |
| working-temperature-%e2%84%83 | -20°C to +60°C |
