The Uniross CR2450 HP is the highest capacity cell in the 24mm HP family, delivering 620 mAh at a stable 3V in a 24.5mm diameter, 5.0mm profile. The additional height over the CR2430 HP more than doubles the available capacity while retaining the same 8 mA continuous and 28 mA pulse ratings. The CR2450 HP is the standard specification for long-life IoT infrastructure, industrial wireless nodes, and medical devices where multi-year battery operation is a design requirement alongside high-drain burst capability.
| Battery Type | CR2450 |
|---|---|
| Chemistry | Lithium Manganese Dioxide (Li-MnO₂) |
| Nominal Voltage (V) | 3 |
| Typical Capacity (mAh) | 620 |
| Standard Current (mA) | 0.4 |
| Continuous Current (Max)( mA) | 8 |
| Pulse Current (Max) (mA) | 28 |
| Max Dimensions (mm) | ø24.5 x 5.0 mm |
| Weight Approx (g) | 6.9 |
| Shelf life | 10 Years |
| Working Temperature (°C) | -20°C to +60°C |
