The Uniross CR2430 HP delivers 300 mAh at a stable 3V in a 24.5mm diameter, 3.0mm profile, stepping up to the higher current class of the 24mm HP family with 8 mA continuous and 28 mA pulse ratings. The move to the 24mm footprint from 20mm provides 22% more capacity in a comparable profile height, making the CR2430 HP the preferred specification for medical monitoring devices, smart metering, and industrial wireless instruments that require both high peak current and extended runtime in a standard coin cell format.
| Battery Type | CR2430 |
|---|---|
| Chemistry | Lithium Manganese Dioxide (Li-MnO₂) |
| Nominal Voltage (V) | 3 |
| Typical Capacity (mAh) | 300 |
| Standard Current (mA) | 0.2 |
| Continuous Current (Max)( mA) | 8 |
| Pulse Current (Max) (mA) | 28 |
| Max Dimensions (mm) | ø24.5 x 3.0 mm |
| Weight Approx (g) | 4.5 |
| Shelf life | 10 Years |
| Working Temperature (°C) | -20°C to +60°C |
