The Uniross CR2325T HT delivers 190 mAh at a stable 3V in the 23mm diameter, 2.5mm profile — 46% more capacity than the CR2320T HT with an additional 0.5mm of height. With 6 mA continuous and 20 mA pulse ratings and a -30°C to +80°C operating range, the CR2325T HT provides a strong combination of capacity and current performance for demanding wireless applications in automotive and industrial temperature environments.
| Battery Type | CR2325T |
|---|---|
| Chemistry | Lithium Manganese Dioxide (Li-MnO₂) |
| Nominal Voltage (V) | 3 |
| Typical Capacity (mAh) | 190 |
| Standard Current (mA) | 0.2 |
| Continuous Current (Max)( mA) | 6 |
| Pulse Current (Max) (mA) | 20 |
| Max Dimensions (mm) | ø23.0 x 2.5 mm |
| Weight Approx (g) | 3.3 |
| Shelf life | 7 Years |
| Working Temperature (°C) | -30°C to +80°C |
