The Uniross CR2320T HT delivers 130 mAh at a stable 3V in the slim 23mm diameter, 2.0mm profile — the entry point to the 23mm HT family and its higher current class of 6 mA continuous and 20 mA pulse. The wider electrode area of the 23mm format provides the additional current headroom compared to the 20mm family, while the HT construction maintains the -30°C to +80°C operating range required for automotive and outdoor industrial applications.
| Battery Type | CR2320T |
|---|---|
| Chemistry | Lithium Manganese Dioxide (Li-MnO₂) |
| Nominal Voltage (V) | 3 |
| Typical Capacity (mAh) | 130 |
| Standard Current (mA) | 0.2 |
| Continuous Current (Max)( mA) | 6 |
| Pulse Current (Max) (mA) | 20 |
| Max Dimensions (mm) | ø23.0 x 2.0 mm |
| Weight Approx (g) | 3.0 |
| Shelf life | 7 Years |
| Working Temperature (°C) | -30°C to +80°C |
