The Uniross CR2025T HT delivers 150 mAh at a stable 3V in the 20mm diameter, 2.5mm profile — 15% more capacity than the CR2020T HT in a profile that remains compatible with the vast majority of 20mm coin cell housings. The 5 mA continuous and 15 mA pulse ratings and -30°C to +80°C HT operating range make the CR2025T HT the preferred mid-height specification for the 20mm family wherever the design budget allows the additional 0.5mm over the CR2020T.
| Battery Type | CR2025T |
|---|---|
| Chemistry | Lithium Manganese Dioxide (Li-MnO₂) |
| Nominal Voltage (V) | 3 |
| Typical Capacity (mAh) | 150 |
| Standard Current (mA) | 0.2 |
| Continuous Current (Max)( mA) | 5 |
| Pulse Current (Max) (mA) | 15 |
| Max Dimensions (mm) | ø20.0 x 2.5 mm |
| Weight Approx (g) | 2.6 |
| Shelf life | 7 Years |
| Working Temperature (°C) | -30°C to +80°C |
