Uniross CR2025 lithium coin cells deliver 150 mAh at 3V in a 20mm diameter, 2.5mm profile — the slim alternative to the CR2032, sharing the same footprint diameter but in a 0.7mm thinner package. Where device housings are designed for the 20mm footprint but 3.2mm cell height cannot be accommodated, the CR2025 is the direct specification substitute, delivering 68% of the CR2032’s capacity in a lower-profile package with identical current ratings. It is widely specified across automotive, IoT, and medical applications requiring a height-constrained 20mm primary power source.
| Battery Type | CR2025 |
|---|---|
| Chemistry | Lithium Manganese Dioxide (Li-MnO₂) |
| Nominal Voltage (V) | 3V |
| Typical Capacity (mAh) | 150 mAh |
| Continuous Current (Max)( mA) | 5 mA |
| Pulse Current (Max) (mA) | 15 mA |
| Max Dimensions (mm) | ø20.0 x 2.5 mm |
| Weight Approx (g) | 2.6 g |
| Shelf life | 5 Years |
| Working Temperature (°C) | -20°C to +60°C |
