The Uniross CR2025 HP delivers 165 mAh at a stable 3V in the standard 20mm diameter, 2.5mm mid-height profile. With 6 mA continuous and 18 mA pulse current capability, the CR2025 HP occupies the mid-point of the 20mm HP family — significantly more capacity than the CR2016 HP in a profile that still fits most automotive key and wearable housings designed around the 20mm standard. The HP configuration makes it the correct specification for applications that exhaust standard CR2025 cells prematurely under high-drain duty cycles.
| battery-type | CR2025 |
|---|---|
| chemistry | Lithium Manganese Dioxide (Li-MnO₂) |
| nominal-voltage-v | 3 |
| typical-capacity-mah | 165 |
| standard-current-ma | 0.2 |
| continuous-current-max-ma | 6 |
| pulse-current-max-ma | 18 |
| max-dimensions-mm | ø20.0 x 2.5 mm |
| weight-approx-g | 2.7 |
| shelf-life | 10 Years |
| working-temperature-c | -20°C to +60°C |
