Uniross CR2016 lithium coin cells deliver 80 mAh at 3V in a 20mm diameter, 1.6mm profile — the thinnest primary cell in the widely adopted 20mm coin cell family. The 20mm footprint supports current ratings of 5 mA continuous and 15 mA pulse, significantly higher than the 16mm series, making the CR2016 the specification of choice for slim devices that require more current drive capability alongside a flat-profile housing constraint. Specified across key fob designs, thin medical devices, and slim-form IoT hardware requiring a balance of current capability and minimal height.
| Battery Type | CR2016 |
|---|---|
| Chemistry | Lithium Manganese Dioxide (Li-MnO₂) |
| Nominal Voltage (V) | 3V |
| Typical Capacity (mAh) | 80 mAh |
| Continuous Current (Max)( mA) | 5 mA |
| Pulse Current (Max) (mA) | 15 mA |
| Max Dimensions (mm) | ø20.0 x 1.6 mm |
| Weight Approx (g) | 2.0 g |
| Shelf life | 5 Years |
| Working Temperature (°C) | -20°C to +60°C |
