The Uniross CR1632T HT is the highest capacity cell in the 16mm HT family, delivering 120 mAh at a stable 3V in a 16mm diameter, 3.2mm profile. The full 3.2mm height extracts maximum electrode area from the 16mm footprint, providing 71% more capacity than the CR1620T HT for extended-runtime applications. With 3 mA continuous and 8 mA pulse ratings and a -30°C to +80°C operating range, the CR1632T HT is the specification of choice for 16mm housings where runtime and temperature qualification are both critical requirements.
| Battery Type | CR1632T |
|---|---|
| Chemistry | Lithium Manganese Dioxide (Li-MnO₂) |
| Nominal Voltage (V) | 3 |
| Typical Capacity (mAh) | 120 |
| Standard Current (mA) | 0.1 |
| Continuous Current (Max)( mA) | 3 |
| Pulse Current (Max) (mA) | 8 |
| Max Dimensions (mm) | ø16.0 x 3.2 mm |
| Weight Approx (g) | 2.0 |
| Shelf life | 7 Years |
| Working Temperature (°C) | -30°C to +80°C |
