The Uniross CR1616T HT delivers 50 mAh at a stable 3V in a 16mm diameter, 1.6mm ultra-thin profile — the slimmest cell in the 16mm HT family. Moving up to the 16mm footprint brings a step-up in current capability to 3 mA continuous and 8 mA pulse, while the HT construction maintains the -30°C to +80°C operating range. The CR1616T HT is specified where slim housing depth and temperature qualification are simultaneous requirements in automotive or industrial designs.
| Battery Type | CR1616T |
|---|---|
| Chemistry | Lithium Manganese Dioxide (Li-MnO₂) |
| Nominal Voltage (V) | 3 |
| Typical Capacity (mAh) | 50 |
| Standard Current (mA) | 0.1 |
| Continuous Current (Max)( mA) | 3 |
| Pulse Current (Max) (mA) | 8 |
| Max Dimensions (mm) | ø16.0 x 1.6 mm |
| Weight Approx (g) | 1.2 |
| Shelf life | 7 Years |
| Working Temperature (°C) | -30°C to +80°C |
