The Uniross CR1225T HT is the highest capacity cell in the 12.5mm HT family, delivering 50 mAh at a stable 3V in a 12.5mm diameter, 2.5mm profile. It provides the maximum runtime available in the 12mm coin cell format while retaining the full -30°C to +80°C operating envelope of the HT range. For designs constrained to the 12.5mm footprint that operate in elevated-temperature environments, the CR1225T HT is the definitive specification.
| Battery Type | CR1225T |
|---|---|
| Chemistry | Lithium Manganese Dioxide (Li-MnO₂) |
| Nominal Voltage (V) | 3 |
| Typical Capacity (mAh) | 50 |
| Standard Current (mA) | 0.1 |
| Continuous Current (Max)( mA) | 2 |
| Pulse Current (Max) (mA) | 5 |
| Max Dimensions (mm) | ø12.5 x 2.5 mm |
| Weight Approx (g) | 0.9 |
| Shelf life | 7 Years |
| Working Temperature (°C) | -30°C to +80°C |
